Anti Finger Galvalume Steel Coil G550 Aluzinc Zinc Aluminum Alloy Coated

Place of Origin China
Brand Name Sincere
Certification ISO14000
Model Number N/A
Minimum Order Quantity 25 MT
Packaging Details Standard export packing
Delivery Time 35 Days
Payment Terms TT / LC
Supply Ability 10000 MT per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571


If you have any concern, we provide 24-hour online help.

Product Details
Thickness 2.30mm Name Galvanized Coil
Width Max 1524mm Zinc Coating AZ50 - AZ185
High Light

Anti Finger Galvalume Steel Coil


G550 Galvalume Steel Coil


Aluminum Alloy Coated Galvalume Steel Coil

Leave a Message
Product Description

Galvalume Steel Coil Anti Finger G550 Coil Aluzinc Zinc Aluminum Alloy Coated Steel


Hot dipped Galvalume steel is carbon steel coated with an aluminum-zinc alloy using a continuous hot-dip process, combining the corrosion protection and high-temperature resistance of aluminum with the formability and galvanic protection of zinc. The coating composition consists of 55% aluminum, 43.4% zinc, and 1.6% silicon, respectively, by weight.



The current main products are covering Cold Rolled series (coils/sheets), Metallic Coated series (GI,GL,galvanized, galvalumed, aluzinc, zincalume), Color Coated series (PPGI,PPGL) and their derivatives (Corrugated,Trapezoidal, Roofing sheets and Cladding). All of these products are enjoying great popularity and widely used in our daily life as well as infrastructure construction, transportation, warehousing and home appliance industry, etc.



Grade SGLCC,SGLCH,G550,G350
Thickness 0.13-1.0mm
Width 600-1500 mm
Zinc Coating AZ30-150g/m2
Content 55% alu,43.5%zinc,1.5% Si
Surface treatment Light Oil, oil, dry, chromate, passivated, Anti finger
Spangle Minimal spangle
Coil Weight 2-5 tons
Coil ID 508/610 mm



EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
0.12-4.00mm, or customer's requirement
600mm-1500mm, according to customer's requirement
Type of Coating
Hot Dipped Galvanized Steel(HDGI)
Zinc Coating
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Coil Weight
3-20 metric ton per coil
Water proof paper is inner packing, galvanized steel or coated steel sheet is outer packing , side guard plate, then wrapped by
seven steel belt. or according to customer's requirement
